Furuno GP320B WAAS-GPS Receiver Antenna

A high performance GPS Receiver

The Furuno GP320B WAAS-GPS Receiver Antenna
matches any NavNet product capable of receiving
WAAS and GPS information. Now there is no need to have a separate
unit to get your WAAS/GPS fix. This WAAS/GPS Receiver Antenna has
everything you need built-in, so it can deliver accuracy better
than 3 metres by decoding GPS correction signals from the WAAS
(Wide Area Augmentation System).

Furuno GP320B WAAS-GPS Receiver Antenna
Features:

• WAAS (Wide Area Augmentation System) Receiver
• 12 Channel, All-in-View Parallel Tracking GPS Receiver
• Up to 900 Knot Tracking Velocity
• 90 Second Cold Start Acquisition, 20 Second Warm State
  Acquisition
• 3M Accuracy or higher (95% of the time, SA off)
• WAAS On/Off Selectable
• Display: Black Box
• Power Supply: 12 VDC

Furuno GP320B WAAS-GPS Receiver Antenna
Specifications:

• Receiving Type: 12 discrete channels, C/A code, all-in-view,
  SBAS (WAAS/EGNOS/MSAS)
• Receiving Frequency L1（1575.42 MHz）
• Accuracy: GPS at 10 m, MSAS at 7 m, WAAS at 3 m
• Chart Plotter: WGS-84, NAD-27 and others
• Waterproofing: IEC60529 IPX6
• Power Supply: DC 12-24 V、0.11-0.06 A
• Weight: 0.8　kg
